Changzhou Longs Motor Co.,Ltd
|
DC Brushless Motor
| Place of Origin: | Jiangsu, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
57BL
Features:
Model: 57BL01; 57BL02; 57BL03; 57BL04;57BL05;57BL06
Number of Poles: 8
Number of Phases: 3
Nominal Voltage VDC: 24
Rated speed RPM: 2500~3000
Continuous Torque N-m: 0.057~0.44
Output Power Watts: 15~138
Peak Torque1 N-m: 0.18~1.6
Peak Current Amps: 2.7~25.8
Line to line Resistance Ohms: 0.35~3.6
Line to line Inductance mH: 0.5~2.6
Torque constant N-m/Amps: 0.059~0.074
Back EMF V/kRPM: 6.2~7.75
Rotor inertia g·cm2: 32~140
Body Length (L) mm: 37~107
Mass kg: 0.43~1.25
